دستگاه تولیدی پوشک بزرگسالان

High-Performance Full Servo Adult Diaper Making Machine for Large-Scale Production Needs

تمام دسته ها

دستگاه پوشاک شلوار

با ما تماس بگیرید

Mrs. Jessie

jessie@wm-machinery.com

18859442931

حالا تماس بگیرید

High-Performance Full Servo Adult Diaper Making Machine for Large-Scale Production Needs

نام تجاری:	Womeng
شماره مدل:	WM-SCK02
مقدار تولیدی:	1 قطعه
قیمت:	$500,000.00-$800,000.00
جزئیات بسته بندی:	جعبه چوبی با ارزش دریا
شرایط پرداخت:	L/C ، D/A ، D/P ، T/T

اطلاعات دقیق

توضیح محصول

اطلاعات دقیق

محل منبع:

فوجیان ، چین

گواهی:

کارایی:

طراحی:

سیستم کنترل کامل سروو

خط تولید:

کاملاً اتوماتیک

ظرفیت:

250-400 قطعه/دقیقه

سیستم جمع آوری زباله:

جمع آوری زباله های خودکار

ولتاژ:

380 ولت

سیستم کنترل:

سیستم کنترل PLC

تولید خودکار ، راندمان بالا ، عملکرد پایدار

سیستم انبار:

سیستم انباشت خودکار

رنگ ماشین:

با توجه به سفارشی

قابلیت ارائه:

12Set/سال

برجسته کردن:

full servo adult diaper machine,large-scale diaper production machine,high-performance adult diaper making machine

large-scale diaper production machine

high-performance adult diaper making machine

توضیح محصول

Product Info

Product size	M: 680X450 L: 800X650 XL: 950X760(Customixed according to customer requirement)
Product structure	Product structure: upper & lower tissue, cotton core (mix with SAP), cover sheet hydrophilic non-woven , ADL (Acquisitiondistribution layer) non-woven,leak guard hydrophobic non-woven back sheet,Waist band non-woven,color pattern sticker,elastic waist band, discarding sticker.
Control system	PLC control system,HMI Operating on the LED touch screen,Configure HDTV monitor
Drive system	Servo Drive(Easy to change size), timing belt and flat belt are import products, and all the key parts, are import bearings.
Tension system	Top tissue paper,bottom tissue paper,hydrophobic nonwoven(leg cuff),top nonwoven,ADL,back sheet,elastic nonwoven are adopt A&B shaft active unwinding by inverter motor.
Safety system	It has safety device on the operating side, matched with urgent stop switch.High audio fan uses sound insulation or silencer.
Packaging system	according to customer requirements with palletizer machine (double push double exit ) adjustable
Materials corrective system	Materials corrective system: Adopt international famous brand deviation correction system
Power	380V, 50HZ three phase five wire
Machine Capacity	400KW (Excluding glue machine and air compressor)
Bleed pressure	0.6-0.8Mpa (Air compressor needs to be prepared by customers)

High-Performance Full Servo Adult Diaper Making Machine for Large-Scale Production Needs 0

High-Performance Full Servo Adult Diaper Making Machine for Large-Scale Production Needs 1

High-Performance Full Servo Adult Diaper Making Machine for Large-Scale Production Needs 2

High-Performance Full Servo Adult Diaper Making Machine for Large-Scale Production Needs 3

High-Performance Full Servo Adult Diaper Making Machine for Large-Scale Production Needs 4

High-Performance Full Servo Adult Diaper Making Machine for Large-Scale Production Needs 6

High-Performance Full Servo Adult Diaper Making Machine for Large-Scale Production Needs 7

High-Performance Full Servo Adult Diaper Making Machine for Large-Scale Production Needs 8

High-Performance Full Servo Adult Diaper Making Machine for Large-Scale Production Needs 11

Whatsapp: +008615805080212

Email:jessie@wm-machinery.com

https://www.diapersmachines.com

Compliance and Safety: Conform to global standards and avoid market risks

Product safety and compliance: The diapers produced by the production line meet international common safety standards such as the EU CE, the US FDA, and ISO (such as "formaldehyde-free, no irritating components, and skin allergenicity up to standard"). Customers can meet the access requirements of the target market without additional modifications, making it particularly suitable for the European and American markets with high safety requirements for products.

Equipment environmental protection and labor safety: The noise (≤75 decibels) and dust emissions (≤XXmg/m³) during the operation of the equipment comply with international environmental protection standards and will not pollute the workshop environment. It is also equipped with safety devices such as emergency stop buttons, guardrails, and heat insulation layers for high-temperature components to protect the safety of workers during operation, meeting the safety production requirements of the International Labour Organization (ILO) and helping customers avoid labor compliance risks.

Traceability support: The production line can be connected to a simple production traceability system (such as recording the raw material source, production time, and operator of each batch of products). In case of product quality issues in the future, customers can quickly locate the cause, which meets the traceability requirements for "medical device products" in some countries (such as the EU MDR regulation).
